Chapter 7 Memory Configuration and Data Process
How to change individually the servo parameter after transfer of
servo parameter
The servo parameters can be individually changed from QD77MS with the
following axis control data.
Buffer memory address
Setting item Setting details
QD77MS2
QD77MS4
QD77MS16
Cd.130
Parameter
write request
Set the write request of servo
parameter.
Set "1" after setting "
Cd.131 Parameter
No.
" and " Cd.132 Change data".
1 : Write request
Other than 1 : Not request
1554+100n 4354+100n
Cd.131
Parameter No.
Set the servo parameter to be
changed.
1555+100n 4355+100n
Cd.132
Change data
Set the change value of servo
parameter set in "
Cd.131 Parameter
No.
".
1556+100n 4356+100n
n: Axis No.-1
POINT
(1) Both of the servo parameter area (internal memory (nonvolatile) and buffer
memory/internal memory) of QD77MS's and the parameter of servo amplifier
are changed.
(2) When the servo parameters that become valid by turning ON the servo
amplifier's power supply are changed, be sure to turn ON
(Note)
twice the servo
amplifier's power supply after change.
(Note): The servo amplifier's RAM data are changed by parameter setting, but
the servo amplifier's EEPROM data are not changed. The EEPROM
data before the change are overwritten to RAM by the servo amplifier's
power supply ON again, and then the servo amplifier starts.
After that, the changed data are written to the servo amplifier's
EEPROM in an initial communication with QD77MS. Therefore, the
changed data are overwritten to the RAM data by turning the servo
amplifier's power supply ON again.
