9 - 82
Chapter 9 Major Positioning Control
Positioning data setting examples
[When "2-axis speed control (forward run: speed 2)" is set in the positioning data
No. 1 of axis 1]
• Reference axis............. Axis 1
• Interpolation axis.......... Axis 2 (The required values are also set in positioning
data No.1 of axis 2.)
QD77MS2/QD77MS4
setting example
QD77MS16
setting example
Axis
Setting item
Axis 1
(reference
axis)
Axis 2
(interpolation
axis)
Axis 1
(reference
axis)
Axis 2
(interpolation
axis)
Setting details
Da.1
Operation pattern
Positioning
complete
–
Positioning
complete
–
Setting other than "Positioning complete" is
not possible in speed control.
Da.2
Control system
Forward run
speed 2
–
Forward run
speed 2
–
Set 2-axis speed control.
Da.3
Acceleration time No. 1 –
1 –
Designate the value set in "
Pr.25
Acceleration time 1" as the acceleration time
at start.
Da.4
Deceleration time No. 0 –
0 –
Designate the value set in "
Pr.10
Deceleration time 0" as the deceleration time
at deceleration.
Da.5
Axis to be interpolated
QD77MS2 QD77MS4
Axis 2
–
Set the axis to be interpolated (partner axis).
If the self-axis is set, an error will occur.
Da.6
Positioning address/
movement amount
– –
– –
Da.7
Arc address – –
– –
Setting not required (setting value is ignored).
Da.8
Command speed
6000.00
mm/min
3000.00
mm/min
6000.00
mm/min
3000.00
mm/min
Set the speed to be commanded.
Da.9
Dwell time – –
– –
Setting not required (setting value is ignored).
Da.10
M code 10 –
10 –
Set this when other sub operation commands
are issued in combination with the No. 1
positioning data. ("
Pr.18 M code ON signal
output timing" setting only possible in the
WITH mode.)
Da.20
Axis to be interpolated
No.1
QD77MS16
Axis 2 –
Set the axis to be interpolated.
If the self-axis is set, an error will occur.
Da.21
Axis to be interpolated
No.2
QD77MS16
– –
Axis 1 Positioning data No. 1
Da.22
Axis to be interpolated
No.3
QD77MS16
– –
Setting not required (setting value is ignored).
(Note): Refer to Section 5.3 "List of positioning data" for information on the setting details.
