(4) When either of three axes exceeds the speed limit, that axis is controlled with
the speed limit value. The speeds of the other axes are limited at the ratios of
"
Da.8 Command speed".
(Examples)
Axis
Setting item
Axis 1 setting Axis 2 setting Axis 3 setting
Pr.8
Speed limit
value
4000.00mm/min 5000.00mm/min 6000.00mm/min
Da.8
Command
speed
8000.00mm/min 6000.00mm/min 4000.00mm/min
With the settings shown above, the operation speed in speed control is as
follows.
Axis 1: 4000.00 mm/min (Speed is limited by
Pr.8 ).
Axis 2: 3000.00 mm/min (Speed is limited at ratios in axes 1, 2, and 3
command speeds).
Axis 3: 2000.00 mm/min (Speed is limited at ratios in axes 1, 2, and 3
command speeds).
(Note): Operation runs at speed 1 when a reference axis speed is less than 1
as a result of speed limit.
In addition, when "
Pr.7 Bias speed at start" is set, the set value will be
the minimum speed.
(5) An error "No command speed (error code: 503)" will occur if a current speed
(-1) is set in "
Da.8 Command speed".
(6) The software stroke limit check is not carried out when the control unit is set to
"degree".
To Next Page
