2 - 6
Chapter 2 System Configuration
(b) Mounting to a MELSECNET/H remote I/O station
Base unit
(Note-2)
Applicable
network module
No. of modules
(Note-1)
Main base unit of
remote I/O station
Extension base unit of
remote I/O station
QJ72LP25-25
QJ72LP25G
QJ72BR15
Max. 64 modules
: Installation possible, : Installation not possible
(Note-1): Within the I/O point range of network module only.
(Note-2): It can be installed in any of the I/O slots of installable base unit.
REMARK
The basic model QCPU cannot configure the MELSECNET/H remote I/O network.
(2) Compatibility with Multiple PLC system
When using the QD77MS in a Multiple PLC system, first refer to the QCPU
User's Manual (Multiple CPU system).
(3) Programming tool
The applicable programming tool's versions of the QD77MS are shown below.
(For the applicable programming tool's versions of the CPU module, refer to the
"QCPU User's Manual (Hardware Design, Maintenance and Inspection)".)
Version
GX Works2 MR Configurator2
QD77MS2
QD77MS4
QD77MS16
Version 1.77F or later Version 1.09K or later
REMARK
QD77MS cannot be supported with GX Developer, GX Configurator-QP and
MR Configurator.
Use GX Works2 and MR Configurator2 to use QD77MS.
