13 - 102
Chapter 13 Control Sub Functions
[2] Setting method of "Speed control 10 x multiplier setting for degree
axis function"
Normally, the speed specification range is 0.001 to 2000000.000[degree/min],
but it will be decupled and become 0.01 to 20000000.00[degree/min] by setting
"
Pr.83
Speed control 10 x multiplier setting for degree axis" to valid.
The use the "
Pr.83
Speed control 10 x multiplier setting for degree axis function",
set the parameters shown in the following table.
Buffer memory address
Setting item
Setting
value
Setting details
QD77MS2
QD77MS4
QD77MS16
Pr.83
Speed control 10
x multiplier setting
for degree axis
Set the speed control 10 x multiplier setting for
degree axis.
0: Invalid
1: Valid
63+150n
n: Axis No.-1
: Refer to Section 5.2.4 "Detailed parameters 2" for details on the setting details.
