14 - 28
Chapter 14 Common Functions
Pr.800
Mark detection signal setting
Set the input signal for mark detection.
0 : Invalid
1 to 2 : External command signal [DI] of axis 1 to axis 2 (QD77MS2)
1 to 4 : External command signal [DI] of axis 1 to axis 4 (QD77MS4)
1 to 16 : External command signal [DI] of axis 1 to axis 16 (QD77MS16)
Set "4: High speed input request" in "
Pr.42 External command function selection" and
set "1: Validates an external command." in "
Cd.8 External command valid".
Pr.801
Mark detection signal compensation time
Compensate the input timing of the mark detection signal.
Set this parameter to compensate such as delay of sensor input. (Set a positive
value to compensate for a delay.)
Pr.802
Mark detection data type
Set the data that latched at mark detection.
The target data is latched by setting "0 to 12". Set the axis No. in "
Pr.803 Mark
detection data axis No.
".
Optional 2 word buffer memory is latched by setting "-1". Set the buffer memory
No. in "
Pr.804 Mark detection data buffer memory No.".
0 : Current feed value
1 : Machine feed value
2 : Real current value
3 : Servo input axis current value
6 : Synchronous encoder axis current value
7 : Synchronous encoder axis current value per cycle
8 : Current value after composite main shaft gear
9 : Current Value per cycle after main shaft gear
10 : Current value per cycle after auxiliary shaft gear
11 : Cam axis current value per cycle
12 : Cam axis current value per cycle (Real position)
-1 : Optional 2 words buffer memory
