Chapter 16 Troubleshooting
Related buffer memory address
QD77MS2
QD77MS4
QD77MS16
Set range
(Setting with sequence program)
Remedy
6+150n
7+150n
0 [PLS/s]
0 [
10
-2
mm/min or others]
• Set the bias speed to not more than the speed limit value.
• With the setting brought into the setting range, turn the PLC
READY signal [Y0] from OFF to ON.
Unit magnification
1+150n
Number of pulses per rotation
2+150n
3+150n
Movement amount per rotation
4+150n
5+150n
0.001 ≤ Electronic gear ≤ 20000
Electronic gear =
Pr.2
Pr.3 × Pr.4
"
Pr.2 Number of pulses per rotation (AP)",
"
Pr.3 Movement amount per rotation (AL)",
"
Pr.4 Unit magnification (AM)"
Review these parameters .
(Refer to Section 5.2.1)
10+150n
11+150n
<Speed limit value>
1 to 1000000000 [PLS/s]
1 to 2000000000 [
10
-2
mm/min or others]
• Set a value which is not less than the OPR speed.
• With the setting brought into the setting range, turn the PLC
READY signal [Y0] from OFF to ON.
12+150n
13+150n
1 to 8388608
14+150n
15+150n
1 to 8388608
With the setting brought into the setting range, turn the PLC
READY signal [Y0] from OFF to ON.
17+150n
0 ≤
Pr.11 × Pr.2
Pr.3 × Pr.4
≤ 65535
"
Pr.2 Number of pulses per rotation (AP)",
"
Pr.3 Movement amount per rotation (AL)",
"
Pr.4 Unit magnification (AM)"
"
Pr.11 Backlash compensation amount"
Review the items above.
(Refer to Section 5.2.1 or Section 5.2.3)
18+150n
19+150n
• [mm] [inch] [PLS]
–2147483648 to 2147483647
• [degree] 0 to 35999999
20+150n
21+150n
• [mm] [inch] [PLS]
–2147483648 to 2147483647
• [degree] 0 to 35999999
• Bring the setting into the setting range.
• In a unit other than degree, set so that the lower limit value is
smaller than the upper limit value.
22+150n 0, 1
• Bring the setting into the setting range.
• In the unit of "degree", set "0: Apply software stroke limit on
current feed value".
23+150n 0, 1
With the setting brought into the setting range, turn the PLC
READY signal [Y0] from OFF to ON.
