Mitsubishi MELSEC-Q QD77MS

16 - 43
Chapter 16 Troubleshooting
Related buffer memory address
QD77MS2
QD77MS4
QD77MS16
Set range
(Setting with sequence program)
Remedy
48+150n
49+150n
<JOG speed limit value>
1 to 1000000000 [PLS/s]
1 to 2000000000 [
10
-2
mm/min or others]
• With the setting brought into the setting range, turn the PLC
READY signal [Y0] from OFF to ON.
• Bring the setting into the speed limit value or below.
50+150n 0, 1, 2, 3
51+150n 0, 1, 2, 3
52+150n 0, 1
53+150n 1 to 100
54+150n
55+150n
1 to 8388608
56+150n 0, 1
57+150n 0, 1
58+150n 0, 1
60+150n
61+150n
0 to 10000
62+150n 0, 1, 2, 3
64+150n
65+150n
0 to 327680
63+150n 0, 1
With the setting brought into the setting range, turn the PLC
READY signal [Y0] from OFF to ON.
30210+200n
Set with
GX Works2
—
Set the number of master axis not more than the number can
be set in servo parameter "PD15".
30215+200n
30216+200n
30217+200n
30218+200n
Set with
GX Works2
—
Review the master axis No. of servo parameters "PD20 to
PD23".
