Chapter 16 Troubleshooting
Related buffer memory address
QD77MS2
QD77MS4
QD77MS16
Set range
(Setting with sequence program)
Remedy
1538+100n 4338+100n
<Target position change request flag>
1: Target position change request
• Do not turn ON the target position change request in
the following cases.
1) An operating pattern "continuous path control" is
used.
2) A control system other than ABS1, and INC1 is
used.
3) During deceleration stop.
4) When speed change 0 flag (
Md.31 Status: b10) is
ON.
5) During speed control mode
6) During torque control mode
7) During continuous operation to torque control
mode
• When the target position change address is outside
the software stroke limit range, correct the target
position change address. (Refer to Section 13.5.5)
Command torque at torque control
mode
1580+100n 4380+100n
<Command torque at torque control mode>
-10000 to 10000 [
10
-1
%]
Target torque at continuous operation
to torque control
1590+100n 4390+100n
Torque limit setting value
< Target torque at continuous operation to
torque control >
-10000 to 10000 [
10
-1
%]
26+150n
<Torque limit setting value>
1 to 1000[%]
Review the setting value so that the setting torque is
not exceeded the torque limit setting value.
Operation setting for speed-torque
control mode
68+150n
<Torque initial value selection (b4 to b7)>
0, 1
POL reflection setting during torque
control
30192+200n 28492+100n
<POL reflection setting during torque
control>
0, 1
• Use a servo amplifier which supports the servo
parameter "Function selection C-B
POL reflection
setting during torque control
(PC29)" and set (PC29) to
"1: Invalid.
• Set the torque initial value selection invalid to
command torque.
