Mitsubishi MELSEC-Q QD77MS

Appendix - 15
Appendices
The following shows the relation between the buffer memory addresses of servo
parameter and the various items.
(Note): The setting range is different depending on the servo amplifier model. Refer to
the "Servo amplifier Instruction Manual" for details.
Buffer memory address
QD77MS2
QD77MS4
QD77MS16
Compatibility
of setting value
of QD77MS2/
QD77MS4 and
QD77MS16
Item
Servo amplifier
parameter No.
Memory
area
30100+200n 28400+100n Pr.100
Servo series
–
30101+200n 28401+100n
– PA01
30102+200n 28402+100n
– PA02
30103+200n 28403+100n
– PA03
30104+200n 28404+100n
– PA04
30105+200n 28405+100n
– PA05
30106+200n 28406+100n
– PA06
30107+200n 28407+100n
– PA07
30108+200n 28408+100n
– PA08
30109+200n 28409+100n
– PA09
30110+200n 28410+100n
– PA10
30111+200n 28411+100n
– PA11
30112+200n 28412+100n
– PA12
30113+200n 28413+100n
– PA13
30114+200n 28414+100n
– PA14
30115+200n 28415+100n
– PA15
30116+200n 28416+100n
– PA16
30117+200n 28417+100n
– PA17
30118+200n 28418+100n
– PA18
30932+50n
Set with
GX Works2
–
PA19
64400+250n 64400+70n
–
PA20
64401+250n 64401+70n
–
PA21
64402+250n 64402+70n
–
PA22
64403+250n 64403+70n
–
PA23
64404+250n 64404+70n
–
PA24
64405+250n 64405+70n
–
PA25
64406+250n 64406+70n
–
PA26
64407+250n 64407+70n
–
PA27
64408+250n 64408+70n
–
PA28
64409+250n 64408+70n
–
PA29
64410+250n 64410+70n
–
PA30
64411+250n 64411+70n
–
PA31
64412+250n 64412+70n
–
PA32
Servo
parameters
n: Axis No.-1
: Compatible : Partly compatible : Not compatible
