Mitsubishi MELSEC-Q QD77MS User Manual

Appendix - 26
Appendices
Buffer memory address
QD77MS2
QD77MS4
QD77MS16
Compatibility
of setting value
of QD77MS2/
QD77MS4 and
QD77MS16
Item
Servo amplifier
parameter No.
Memory
area
64592+250n
– PL41
64593+250n
– PL42
64594+250n
– PL43
64595+250n
– PL44
64596+250n
– PL45
64597+250n
– PL46
64598+250n
– PL47
64599+250n
– PL48
64600+250n
– PT01
64601+250n
– PT02
64602+250n
– PT03
64603+250n
– PT04
64604+250n
– PT05
64605+250n
– PT06
64606+250n
– PT07
64607+250n
– PT08
64608+250n
– PT09
64609+250n
– PT10
64610+250n
– PT11
64611+250n
– PT12
64612+250n
– PT13
64613+250n
– PT14
64614+250n
– PT15
64615+250n
– PT16
64616+250n
– PT17
64617+250n
– PT18
64618+250n
– PT19
64619+250n
– PT20
64620+250n
– PT21
64621+250n
– PT22
64622+250n
– PT23
64623+250n
– PT24
64624+250n
– PT25
64625+250n
– PT26
64626+250n
– PT27
64627+250n
– PT28
64628+250n
– PT29
64629+250n
– PT30
64630+250n
– PT31
64631+250n
Set with
GX Works2
– PT32
Servo
parameters
n: Axis No.-1
