Appendix - 41
Appendices
1) The following table indicates the external input signal cables. Make
selection according to your operating conditions.
Table 3.1 Table of wire specifications
Characteristics of one core
Wire model
Core size
[mm
2
]
Number of
cores
Structure
[Number of
wires/mm]
Conductor
resistance
[
/km]
Insulating
sheath OD
d[mm]
(Note-1)
Finish OD
[mm]
(Note-2)
17/0.16 1P SRV-SV(2464)-K
0.3mm
2
2(1 pairs) 17/0.16 57.5 0.77 5.3
17/0.16 4P SRV-SV(2464)-K
0.3mm
2
8(4 pairs) 17/0.16 57.5 0.77 7.6
17/0.16 10P SRV-SV(2464)-K
0.3mm
2
20(10 pairs) 17/0.16 57.5 0.77 10.0
(Note-1): d is as shown below.
Insulation sheath
Conductor
d
(Note-2): Standard OD. Max. OD is about 10% larger.
CAUTION
When fabricating the cable, do not make incorrect connection. Wrong connection will cause runaway or
explosion.
To Next Page
