MLC LC100 - Page 115

115
LC100 Instruction manual
NO
DYSPLAY ON LC100-D
DESCRIPTION
FI-334
Shaft light control input function.
FI-335
Information input Alarm button is pressed.
FI-336
Control input for light curtain of door A.
FI-337
Control input for light curtain of door B.
FI-338
Control input for temperature of door A.
FI-339
Control input for temperature of door B.
FI-340
Input for door A open pushbutton – additional time.
FI-341
Input for door B open pushbutton – additional time.
FI-342
Input for control of the UPS, once a day.
FI-343
Input for control service pit door. Writes in statistic, for normal travel need to
do reset.
FI-344
Input for control safety gear. Writes in statistic, for normal travel need to do
reset.
FI-345
Input information that the STOP on the cabinet is activated.
FI-346
Input information that the STOP on the cabin is activated.
FI-347
Input information that the STOP near machine is activated.
FI-348
Input information that the STOP in the pit is activated.
FI-349
Additional input for UP travel contactor control for hydraulic elevators.
FI-350
Additional input for DOWN travel contactor control for hydraulic elevators.
FI-351
Additional input for control motor contactots for VVVF elevators.
FI-352
Additional input for brake control for VVVF elevators.
FI-353
Additional input for reset error/controller.
FI-354
Additional input for reset small pit status.
FI-355
Input for controlling the EUCM contactor.
