MLC LC100 - 4.9 Protection - Type I

102
LC100 Instruction manual
4.9 Protection - Type I
4/6 Parameters
9/12 Protection
Type I
I-01
Cold state PTC resistance
0-9999
Cold state PTC resistance.
When the resistance of the PTC probe connected to the input XC8:2 rises
above the value defined by parameter I-02 elevator ends current travel,
activates motor fan, if there is any, and waits for PTC resistance to fall below
the value I-01.
I-02
Warm state PTC resistance
0-9999
Warm state PTC resistance.
I-03
Normal travel max. time
0-250s
Maximum time of normal travel.
I-04
Leveling max. time
0-250s
Maximum time of leveling travel. Maximal time of traveling in low speed. From
order to slow to activating stoping in station switch should not take more than
the time set by parameter . Otherwise elevator indicates error „slow speed fail.“.
I-05
Releveling max. time
0-250s
Maximum time of relevening. From order to relevel to activating stoping in
station switch should not take more than the time set by the parameter.
Otherwise elevator indicates error „releveling fail.“
I-06
Evacuation max. time
0-250s
Maximum evacuation travel time. Maximum passenger evacuation time from
cabin.
