MLC LC100 - Page 67

67
LC100 Instruction manual
134
Indicates that light curtain B are defective and closing door work with
nudging.
135
Indicates that service door are opened FI-343.
136
Indicates that safety gear is active FI-344.
137
Indicates that STOP are active in the cabinet FI-345.
138
Indicates that STOP are active on the cabine FI-346.
139
Indicates that STOP near machine are active FI-347.
140
Indicates that STOP in the pit are active FI-348.
141
--
142
Cabin door A contact failure.
143
Cabin door B contact failure.
144
Locking device door A contact failure.
145
Locking device door B contact failure.
155
Indicates that when attempting to drive overspeed governor contactor
was not powered on. Control of the overspeed governor contactor is done
trough the input with the function FI-291.
Fault must be reset trough reset button on the LC100-D2 keypad.
156
Indicates that when stopping the elevator overspeed governor
contactor was not powered off. Control of the overspeed governor contactor
is done trough the input with the function FI-291.
Fault must be reset trough reset button on the LC100-D2 keypad.
157
Indicates stopping zone switch deactivation failure, control of the zone is
done trough the input with the function FI-258.
158
Indicates stopping zone switch activation failure, control of the zone is done
trough the input with the function FI-258.
159
Indicates that when stopping the elevator contactor was not powered
off. Control of the K-EUCM contactor is done trough the input with the
function FI-335.
Fault must be reset trough reset button on the LC100-D2 keypad.
160
Indicates that when attempting to drive NC80 don’t give output to
contactor K-EUCM. Control of the K-EUCM contactor is done trough the
input with the function FI-335.
Fault must be reset trough reset button on the LC100-D2 keypad.
