Serial interface (Modbus)
10/05 AWB8230-1541GB
166
1022 A012 Analog input (O-L) –
frequency at maximum
reference value
rw 0 – 400 Hz 0.1 [Hz]
1023 A013 Analog input (O-L) –
minimum reference value
(offset)
rw 0 – 100 % 1 [%]
1024 A014 Analog input (O-L) –
maximum reference value
(offset)
rw 0 – 100 % 1 [%]
1025 A015 Analog input (O-L) –
selection of starting
frequency applied to the
motor at minimum reference
value
rw 00: Value of PNU A011 –
01: 0Hz
1026 A016 Analog input – filter time
constant
rw 1 – 8 1 [times]
1027 A019 Reserved rw – –
1028 A020 Reserved rw – –
1029 A020 Frequency reference input –
reference value through
keypad, PNU A001 must
equal 02
rw 0–400Hz 0.1 [Hz]
102A A021 Reserved
rw – –
102B A021 Frequency reference input –
fixed frequency (1)
rw 0–400Hz 0.1 [Hz]
102C A022 Reserved rw – –
102D A022 Frequency reference input –
fixed frequency (2)
rw 0–400Hz 0.1 [Hz]
102E A023 Reserved rw – –
102F A023 Frequency reference input –
fixed frequency (3)
rw 0–400Hz 0.1 [Hz]
1030 A024 Reserved
rw – –
1031 A024 Frequency reference input –
fixed frequency (4)
rw 0–400Hz 0.1 [Hz]
1032 A025 Reserved rw – –
1033 A025 Frequency reference input –
fixed frequency (5)
rw 0–400Hz 0.1 [Hz]
1034 A026 Reserved rw – –
1035 A026 Frequency reference input –
fixed frequency (6)
rw 0–400Hz 0.1 [Hz]
1036 A027 Reserved rw – –
1037 A027 Frequency reference input –
fixed frequency (7)
rw 0–400Hz 0.1 [Hz]
1038 A028 Reserved rw – –
1039 A028 Frequency reference input –
fixed frequency (8)
rw 0–400Hz 0.1 [Hz]
103A A029 Reserved
rw – –
Holding
register
Function
code
Name
Access
rights
Value range Manipulated
variable
hex
