Moeller DF51 - Page 171

10/05 AWB8230-1541GB
Holding register (word
variable)
167
103B A029 Frequency reference input –
fixed frequency (9)
rw 0 – 400 Hz 0.1 [Hz]
103C A030 Reserved rw – –
103D A030 Frequency reference input –
fixed frequency (10)
rw 0 – 400 Hz 0.1 [Hz]
103E A031 Reserved rw – –
103F A031 Frequency reference input –
fixed frequency (11)
rw 0 – 400 Hz 0.1 [Hz]
1040 A032 Reserved
rw – –
1041 A032 Frequency reference input –
fixed frequency (12)
rw 0 – 400 Hz 0.1 [Hz]
1042 A033 Reserved
rw – –
1043 A033 Frequency reference input –
fixed frequency (13)
rw 0 – 400 Hz 0.1 [Hz]
1044 A034 Reserved rw – –
1045 A034 Frequency reference input –
fixed frequency (14)
rw 0 – 400 Hz 0.1 [Hz]
1046 A035 Reserved rw – –
1047 A035 Frequency reference input –
fixed frequency (15)
rw 0 – 400 Hz 0.1 [Hz]
1048 A038 Jog mode – jog mode
reference value
rw 0 – 9.99 Hz 0.01 [Hz]
1049 A039 Jog mode – motor stop
method
rw 00: Free coasting –
01: Deceleration ramp
02: DC braking
104A A041 Boost function: DF51 only
rw 00: Manual 00
01: Automatic
104B A042 Boost, manual voltage
boost
rw 0 – 20 % 0.1 [%]
104C A043 Boost, transition frequency
for maximum voltage boost
rw 0 – 50 % 0.1 [%]
104D A044 U/f characteristic
rw 00: Constant torque curve –
01: Reduced torque curve
02: SLV active DV51 only
104E A045 U/f characteristic, output
voltage
rw 0 – 255 1 [%]
104F A046 SLV, gain factor, automatic
voltage compensation
DV51 only
rw 0 – 255 1 [%]
1050 A047 SLV, gain factor, automatic
slip compensation
DV51 only
rw 0 – 255 1 [%]
1051 A051 DC braking
rw 00: OFF, disabled –
01: ON, enabled
1052 A052 DC braking – starting
frequency
rw 0 – 60 Hz 0.1 [Hz]
Holding
register
Function
code
Name
Access
rights
Value range Manipulated
variable
hex
