Moeller DF51 - Page 173

10/05 AWB8230-1541GB
Holding register (word
variable)
169
106E A077 PID control – invert input
signals
rw 00: OFF, disabled, reference value (+), actual
value (–)
–
01: ON, enabled, reference value (–), actual
value (+)
106F A078 PID controller – output
signal limit
rw 0 – 100 % 0.1 [%]
1070 A081 Output voltage (AVR
function)
rw 00: ON, enabled –
01: OFF, disabled
02: DOFF, disabled during deceleration
1071 A082 Output voltage (AVR motor
rated voltage)
rw DF51-32…-…: 200, 215, 220, 230, 240 –
DF51-340-…: 380, 400, 415, 440, 460, 480
Default setting depends on series
1072 A085 Reserved rw – –
1073 A086 Reserved rw – –
1074 A092 Acceleration time 2 (MSB) rw 0.01 – 3000 s 0.01 [s]
1075 A092 Acceleration time 2 (LSB) rw 0.01 – 3000 s
1076 A093 Deceleration time 2 (MSB) rw 0.01 – 3000 s 0.01 [s]
1077 A093 Deceleration time 2 (LSB) rw 0.01 – 3000 s
1078 A094 Acceleration time, specify
signal for changeover from
acceleration time 1 to
acceleration time 2
rw 00: Digital input (2CH) –
01: Frequency (PNU A095 or A096)
1079 A095 Reserved
rw – –
107A A095 Acceleration time, frequency
for changeover from ramp
time 1 to ramp time 2
rw 0.0 – 400 Hz 0.1 [Hz]
107B A096 Reserved
rw – –
107C A096 Deceleration time,
frequency for changeover
from ramp time 1 to ramp
time 2
rw 0.0 – 400 Hz 0.1 [Hz]
107D A097 Acceleration time,
characteristic
rw 00: linear –
01: S curve
107E A098 Deceleration time,
characteristic
rw 00: linear –
01: S curve
107F A101 Reserved rw – –
1080 A101 Analog input (OI-L),
frequency at minimum
reference value
rw 0 – 400 Hz 0.1 [Hz]
1081 A102 Reserved rw – –
1082 A102 Analog input (OI-L),
frequency at maximum
reference value
rw 0 – 400 Hz 0.1 [Hz]
1083 A103 Analog input (OI-L),
minimum reference value
(offset)
rw 0 – 100 % 1 [%]
Holding
register
Function
code
Name
Access
rights
Value range Manipulated
variable
hex
