10/05 AWB8230-1541GB
Holding register (word
variable)
171
109B – Reserved rw – –
…
10A4
10A5 b001 POWER, restarting mode
after power supply
interruption
rw 00: Fault signal E 09, automatic restart at 0 Hz –
01: Automatic restart at set starting frequency
after expiry of time set with PNU b003.
02: After the time set with PNU b003 has
elapsed, the frequency inverter synchronizes
to the current motor rotation speed and the
motor is accelerated to the current reference
value in the set ramp times.
03: After the time set under PNU b003 has
elapsed, the inverter synchronizes to the
current motor rotation speed and the motor
brakes to a stop in the set deceleration time.
A fault message is then displayed.
10A6 b002 POWER, permissible power
supply downtime
rw 0.3 – 25 s 0.1 [s]
10A7 b003 POWER, waiting time before
automatic restart after
power supply failure
rw 0.3 – 100 s 0.1 [s]
10A8 b004 POWER, fault signal on
intermittent supply voltage
failure or undervoltage
rw 00: OFF, disabled –
01: ON, enabled
10A9 b005 POWER, number of
automatic restarting
attempts after intermittent
supply voltage failure or
undervoltage
rw 00: 16 restarts –
01: No limit
10AA b006 Reserved
rw – –
10AB b007 Reserved
rw – –
10AC – Reserved rw – –
10AD b012 Thermal overload, tripping
current
rw 0.2 – 1.2 x Ie [A]
0.2 – 1.2 x Ie [A]
0.01 [%]
10AE b013 Thermal overload,
characteristic (torque curve)
rw 00: Reduced torque 1 –
01: Constant torque
02: Reduced torque 2
10AF b015 Reserved rw – –
10B0 b016 Reserved rw – –
10B1 b017 Reserved
rw – –
10B2 b018 Reserved
rw – –
10B3 b019 Reserved rw – –
10B4 b020 Reserved rw – –
10B5 b021 Motor current limitation –
function
rw 00: OFF, disabled –
01: ON, enabled in acceleration phase and at
constant speed
02: Enabled only at constant speed
Holding
register
Function
code
Name Access
rights
Value range Manipulated
variable
hex
