10/05 AWB8230-1541GB
Holding register (word
variable)
175
10FA Reserved rw
1102
1103 C001 Digital input 1 – function rw 00: FWD: Clockwise rotating field
01: REV: Anticlockwise rotating field
02: CF1: Fixed frequency selection, bit 0 (LSB)
03: CF2: Fixed frequency selection, bit 1
04: CF2: Fixed frequency selection, bit 2
05: CF4: Fixed frequency selection, bit 3 (MSB)
06: JOG, jog mode
07: DB, DC braking
08: SET: Select second parameter set
09: 2CH: Second time ramp
11: FRS: Free run stop (free coasting,
= controller inhibit)
12: EXT: External fault message
13: USP: Unattended start protection
15: SFT: Parameter access inhibit
16: AT: change over to analog input OI
18: RST: Reset fault signal
19: PTC: PTC thermistor input (digital input 5
only)
20: STA: Three-wire control start signal
21: STP: Three-wire control stop signal
22: F/R: Three-wire control, direction of rotation
23: PID: Disable PID control
24: PIDC: Reset integral component of PID
control
27: UP: Acceleration (motor potentiometer)
28: DWMN: Deceleration (motor potentiometer)
29: UDC: Motor potentiometer, reset saved
value of motor potentiometer to 0 Hz
31: OPE: Operator keypad
50: ADD: Offset – add value from PNU A145 to
frequency reference value.
51: F-TM: Digital input, mode: control signal
terminals preferred.
52: RDY: Inverter, reduce response time to
control signals
53: SP-SET: Second parameter set with special
functions
255: -- (no function)
1104 C002 Digital input 2 – function rw Values a PNU C001
Holding
register
Function
code
Name
Access
rights
Value range Manipulated
variable
hex
