Motorola APX 7000 Detailed Service Manual

5-12 Troubleshooting Charts: Power-Up Failure
Power-Up Failure – Low VCC_SW_3.6 Voltage
Low VCC_SW_3.6 Voltage
Measure Radio
Current
Is Standby
Current more
than 15mA above
Average
Board has a short,
Replace VOCON
Yes
Measure the
Voltage at L6501
6 < V < 9?
Proceed to
Incorrect B+
Voltage
Inspect U6504 and
All Supporting
Circuitry
Are Parts Solder
Connections and
Placement Correct
Replace or Repair
Part/s
Replace VOCON
Board
No
No
Yes
No
Yes

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
