Motorola APX 7000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-7
63 LCD_RED0_CONN (R2312) 72 LCD_PIX2_CONN (R2321)
64 LCD_PIX10_CONN (R2313) 73 LCD_PIX1_CONN (R2322)
65 LCD_PIX9_CONN (R2314) 74 LCD_PIX0_CONN (R2323)
66 LCD_PIX8_CONN (R2315) 75 LCD_BLJEO_CONN (R2324)
67 LCD_PIX7_CONN (R2316) 76 GROUND
68 LCD_PIX6_CONN (R2317) 77 GROUND
69 LCD_PIX5_CONN (R2318) 78 GROUND
70 LCD_PIX4_CONN (R2319) 79 GROUND
71 LCD_PIX3_CONN (R2320) 80 GROUND
Table 7-7. J2004 Expansion Board to GCAI
J2004
Pin No.
Description
1 GCAI_EXT_MIC_N 11 GPS_RX
2 GCAI_EXT_MIC_P_2 (R2003) 12 UART_TX
3 GCAI_EXT_SPKR_N_1 (R2014) 13 GPS_TX
4 GCAI_EXT_SPKR_P_1 (R2013) 14 UART_RX
5 GROUND 15 GROUND
6 GCAI_ONE_WIRE_1 16 GCAI_USB_P_GPIO1
7 GCAI_GPIO0_1 (R2004) 17 GCAI_USB_N_GPIO2
8 GROUND 18 GROUND
9 GCAI_VBUS_5V 19 GCAI_RTS_GPIO3_1 (R2007)
10 GCAI_VBUS_5V 20 GCAI_GPIO4_CTS_1 (R2005)
Table 7-8. J2005 Expansion Board to Side Buttons
J2005
Pin No.
Description
J2005
Pin No.
Description
1 GROUND 6 GROUND
2 GROUND 7 CON_SB1_1 (R2010)
3 CON_MONITOR_1 (R2012) 8 CON_INT_PTT_1 (R2009)
4 CON_SB2_1 (R2011) 9 GROUND
5 GROUND 10 GROUND
Table 7-6. J2301 VOCON Board (MNCN6202) to Front Chassis (Continued)
J2301
Pin No.
Description
J2301
Pin No.
Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
