Motorola APX 7000 Detailed Service Manual

7-38 Troubleshooting Tables: List of Board and IC Signals
Table 7-15. U6501 MAKO Pinouts
U6501
Pin No.
Description Comment
Probe Points
Not Shielded Under Shield
A1 N/C MAKO Power Schematic –
A2 V_SAVE MAKO Power Schematic R6579
A12 MAKO_TCXO_24MHZ_OUT MAKO Power Schematic C6536
A13 MAKO_TCXO_24MHZ_IN MAKO Power Schematic C6592, C6535
A14 N/C MAKO Power Schematic –
B1 MAKO_XTAL_32K_OUT MAKO Power Schematic C6541
B2 GROUND MAKO Power Schematic N/A
B3 GROUND MAKO Power Schematic N/A
B4 N/C MAKO Power Schematic –
B13 VBUS_SUPPLY MAKO Power Schematic R6521, C6554, R6529,
R6530, R6541
B14 N/C MAKO Power Schematic –
C1 MAKO_XTAL_32K_IN MAKO Power Schematic C6537
C2 V_SAVE MAKO Power Schematic R6420, C6538
C3 GROUND MAKO Power Schematic N/A
C5 POR MAKO Power Schematic R6203
C13 VBUS2_CMD MAKO Power Schematic N/A
C14 VBUS1_CMD MAKO Power Schematic C6544
D1 MAKO_BAT_7.5V MAKO Power Schematic F_UNSW_B+
Test Point, J3001
Pins_28, 30, 32,
34, and 36
R6506, R6504, C6534
D2 MAKO_BAT_3V6 MAKO Power Schematic R6539
D3 MAKO_BAT_3V6 MAKO Power Schematic R6539
D4 GROUND MAKO Power Schematic N/A
D5 MAKO_INT MAKO Power Schematic N/A
D9 GROUND MAKO Power Schematic N/A
D12 VBUS2 MAKO Power Schematic R6583, R6584
D13 SW5_VDD_1 MAKO Power Schematic C6550, R6528,
C6552
D14 GROUND MAKO Power Schematic N/A
E2 FET_ENX MAKO Power Schematic R6504, C6534
