Motorola APX 7000 Detailed Service Manual

Theory of Operation: Controller 3-63
14 GCAI_SPKR_P
16 GCAI_ONE_WIRE
17 GCAI_USB_P_GPIO0
19 GCAI_VBUS_5V
20 GCAI_VBUS_5V
Table 3-14. P2001 Pin Assignment
P2001 SIGNAL
PIN ASSIGNMENT
34 GCAI_RTS_GPIO_3
36 GCAI_USB_N_GPIO2
38 GCAI_USB_P_GPIO1
40 GCAI_ONE_WIRE
42 GCAI_CTS_GPIO_4
44 GND
46 GCAI_VBUS_5V
48 GCAI_VBUS_5V
50 GCAI_USB_P_GPIO0
52 GCAI_MIC_N
54 GCAI_MIC_P
56 GND
58 GCAI_SPKR_N
60 GCAI_SPKR_P
Table 3-13. J2004 Pin Assignment (Continued)
J2004 PIN
ASSIGNMENT
SIGNAL

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
