3-70 Theory of Operation: Controller
Table 3-18. J3001 Bluetooth Interface Connector
Signal Name Group PHY PHY Group Signal Name
GND GROUND 1 2 GROUND GND
MCLK CAMERA 3 4 CAMERA DATA_0
PCLK CAMERA 5 6 CAMERA DATA_1
OE CAMERA 7 8 CAMERA DATA_2
LINE_VALID CAMERA 9 10 CAMERA DATA_3
FRAME_VALID CAMERA 11 12 CAMERA DATA_4
Flash Mode CAMERA / FLASH 13 14 CAMERA DATA_5
RESET CAMERA 15 16 CAMERA DATA_6
PWRDN CAMERA 17 18 CAMERA DATA_7
I2C_SCL I2C 19 20 CAMERA / FLASH FLASH_PWM
I2C_SDA I2C 21 22 GPIO 3 GPIO
VCC_2.8 PWR 23 24 PWR VCC_1.8
GND GROUND 25 26 GROUND GND
SW_B+ PWR 27 28 GROUND GND
SW_B+ PWR 29 30 PWR UNSW_B+
SW_B+ PWR 31 32 PWR USB_VBUS
USB_DM USB 33 34 GROUND USB_VBUS (GND)
USB_DP USB 35 36 SDIO MMC_CLK
GND GROUND 37 38 SDIO MMC_CLKIN
ONE_WIRE OW 39 40 SDIO MMC_CMD
GPIO_1 / Wakeup GPIO / TYPE 1 41 42 SDIO MMC_DAT0
GPIO_0 / Reset
Out
GPIO 43 44 SDIO MMC_DAT1
GPIO_2 GPIO 45 46 SDIO MMC_DAT2
SSI_RXD_B SSI 47 48 SDIO MMC_DAT3
SSI_RXD_R SSI 49 50 SDIO MMC_CMD_DIR
SSI_TXD_B SSI 51 52 GPIO 5 GPIO
SSI_TXD_R SSI 53 54 SDIO MMC_DAT_DIR1
SSI_FS SSI 55 56 TX_Inhibit TYPE 1
SSI_CLK SSI 57 58 Key_Zeroize TYPE 1
GND GROUND 59 60 GPIO 4 GPIO
