Motorola APX 7000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-9
Table 7-11. U6302 OMAP Pinouts
U6302
Pin
No.
Description Comment
Probe Points
Not Shielded Under Shield
M14 OPT_BD_GPIO_1_INT MMC Interface Schematic J3001_Pin 41
M15 MMC1_OPT 1 MMC Interface Schematic R3007, C3004,
J3001_Pin 38
P11 MMC1_OPT 2 MMC Interface Schematic R3017, C3005,
R3008,
J3001_Pin 40
P18 MMC1_OPT 4 MMC Interface Schematic R3014, C3002,
J3001_Pin 54
P19 MMC1_OPT 3 MMC Interface Schematic R3013, C3001,
J3001_Pin 50
P20 F2_TIMER_OUT MMC Interface Schematic TP6301
R10 MMC2 8 MMC Interface Schematic R6303,
J4001_Pin 21
R11 MMC1_OPT 5 MMC Interface Schematic R3018, C3006,
R3009,
J3001_Pin 42
R18 MMC2_CLK_FB (MMC 9) MMC Interface Schematic J4001_Pin 5
V5 MMC2_DAT0_DIR MMC Interface Schematic J4001_Pin 9
V8 MMC2 6 (MMC2_DAT1) MMC Interface Schematic J4001_Pin 17
V9 MMC2 2 (MMC2_CMD_DIR) MMC Interface Schematic J4001_Pin 13
V10 MMC1_OPT 6 MMC Interface Schematic R6302, C3007,
J4001_Pin 21
V11 MMC1_OPT 0 MMC Interface Schematic J3001_Pin 36 R6304
W8 MMC2 5 (MMC2_DATA_0) MMC Interface Schematic J4001_Pin 15
W10 MMC1_OPT 7 MMC Interface Schematic R3020, C3008,
R3011,
J3001_Pin 46
W11 MMC1_OPT 8 MMC Interface Schematic R3021, C3009,
R3012,
J3001_Pin 48
W15 MMC2 7 MMC Interface Schematic R6303,
J4001_Pin 19
W19 MMC2 4 (MMC2_DAT1_DIR) MMC Interface Schematic J4001_Pin 11
Y8 MMC2 1 (MMC2_CMD) MMC Interface Schematic J4001_Pin 23
Y10 MMC2 0 (MMC2_CLK) MMC Interface Schematic J4001_Pin 3 R6305
A1 DDR_ADDR 3 DDR Interface Schematic N/A

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
