Theory of Operation: Controller 3-61

Table 3-11. P1 Pin Assignment

P1 PIN

ASSIGNMENT

SIGNAL

5GND

6 GCAI_USB_P_GPIO1

7 GCAI_USB_N_GPIO2

9 GCAI_RTS_GPIO_3

10 GCAI_CTS_GPIO_4

11 GCAI_MIC_N

12 GCAI_MIC_P

13 GCAI_SPKR_N

14 GCAI_SPKR_P

16 GCAI_ONE_WIRE

17 GCAI_ GPIO0

19 GCAI_VBUS_5V

20 GCAI_VBUS_5V

Table 3-12. GCAI Connector Pin Assignment

ASSIGNMENT

SIGNAL

AGND

B GCAI_RF_INPUT

CGND

1 GCAI_GPIO0 / PwrOn

2 GCAI_ONE_WIRE

3 GCAI_VBUS_5V

4 GCAI_USB_P_GPIO1 / TxDc / FillReq

5 GCAI_USB_N_GPIO2 / RxDc / FillData

6GND

7 GCAI_SPKR_P / LineOut+

8 GCAI_SPKR_N / LineOut-

9 GCAI_RTS_GPIO_3 / OTG-ID / FillSen

10 GCAI_MIC_P

11 GCAI_MIC_N

12 GCAI_CTS_GPIO_4 / KeyFail / FillClk
