7-4 Troubleshooting Tables: List of Board and IC Signals
Table 7-4. J2101 VOCON Board to Control Top
J2101
Pin No.
Description
J2101
Pin No.
Description
1 VDD_LC 26 CID_R
2 Ground 27 Ground
3 Ground 28 Ground
4 FREQ_LED_W 29 VCC_SW_1.875 (R2101)
5 VCC_2.775 30 VCC_2.775D (R2102)
6 FREQ_LED_G 31 TOP_DIS_D_C
7 VOL 32 OMAP_TDO
8 TX_RX_AMBER_LED 33 Ground
9 BSENS 34 RTCK
10 Ground 35 CID_CLK
11 TG0_CONN 36 3TMS_CON
12 FREQ_SEL_3_CONN 37 Ground
13 TG1_CONN 38 NTRST
14 FREQ_SEL_2_CONN 39 CID_DATA
15 TX_RX_RED_LED 40 CPLD_TDO
16 FREQ_SEL_1_CONN 41 Ground
17 TX_RX_GREEN_LED 42 CPLD_TMS_CON
18 FREQ_SEL_0_CONN 43 CID_CS
19 EMERG_PB 44 TCK_CON
20 SEC_CLEAR_CONN 45 Ground
21 Ground 46 1TDI_CON
22 Ground 47 CID_RST
23 CID_W 48 MACE_TDO
24 CID_G 49 Ground
25 VDD_LC 50 MACE_RTCK
