Motorola APX 7000 Detailed Service Manual

8-184 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/ 700–800 MHz
Figure 8-82. MNUS4002A/E UHF2 Harmonic Filter Circuit
Figure 8-83. MNUS4002A/E 700–800 MHz Harmonic Filter Circuit
RF_OUT_1
IN
C1705
L1701
C1701
C1704
L1700
C1700
1.5PF
2.2PF
3.3PF 6.8PF
12.1NH
12.1NH
C1706
C1707
L1702
C1703C1702
DNP
1PF
100PF
12.1NH
7.5PF 3.3PF
HF_OUT_2
OUT
L1401
C1411
L1410
L1408
C1425
C1424
C1419
C1414
C1418
C1413
.5PF
DNP
7.66NH
1PF
.75PF
33PF
1PF
2PF
7.66NH
1PF
HF_OUT_2
RF_OUT_2
2.55NH
TL4
IN
OUT

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
