Troubleshooting Tables: List of Board and IC Signals 7-55
Table 7-18. U2206 GPS Pinouts
U2206
Pin No.
Description
Probe Points
Not Shielded Under Shield
A1 N/C
A2 N/C
A3 N/C
A4 GROUND N/A
A5 RFA_INP N/A
A6 GROUND N/A
A7 GROUND N/A
B1 GROUND N/A
B2 GROUND N/A
B3 FLTRD_GPS_1.875_RF L2264, C2274, C2279,
C2282
B4 FLTRD_GPS_1.875_RF L2264, C2274, C2279,
C2282
B5 RFA_INM N/A
B6 VTUNE R2247, C2246
B7 FLTRD_GPS_1.875_RF L2264, C2274, C2279,
C2282
C1 NRESET R2202, TP2202 Test Point R2255
C2 GROUND N/A
C3 GROUND N/A
C4 FLTRD_GPS_1.875_RF L2264, C2274, C2279,
C2282
C5 FLTRD_GPS_1.875_RF L2264, C2274, C2279,
C2282
C6 GROUND N/A
C7 GROUND N/A
D1 32KHZ R2216, TP2201 Test Point
D2 FLTRD_GPS_1.875_RF L2264, C2274, C2279,
C2282
D3 GROUND
D4 REF_CLK_IN (26 MHZ) C2238
D5 GROUND N/A
D6 GROUND N/A
