Motorola APX 7000 Detailed Service Manual

7-56 Troubleshooting Tables: List of Board and IC Signals
D7 GROUND N/A
E1 FLTRD_GPS_1.2V_CO
RE
R2294, C2273, C2278,
C2203
E2 FLTRD_GPS_1.2V_CO
RE
R2294, C2273, C2278,
C2203
E3 N/C –
E4 N/C –
E5 FLTRD_GPS_1.875_RF L2264, C2274, C2279,
C2282
E6 FLTRD_GPS_1.8V_IO R2295, C2272, C2277,
C2281
E7 GROUND N/A
F1 N/C –
F2 FLTRD_GPS_1.8V_IO R2201
F3 N/C –
F4 GROUND N/A
F5 GROUND N/A
F6 FLTRD_GPS_1.2V_CO
RE
R2294 R2294, C2273, C2278,
C2203
F7 FLTRD_GPS_1.2V_CO
RE
R2294 R2294, C2273, C2278,
C2203
G1 GROUND N/A
G2 GROUND N/A
G3 GROUND N/A
G4 GROUND N/A
G5 GROUND N/A
G6 GROUND N/A
G7 FLTRD_GPS_1.2V_CO
RE
R2294, C2273, C2278,
C2203
H1 GPS_LNA_PON R2204
H2 N/C –
H3 N/C –
H4 GROUND N/A
Table 7-18. U2206 GPS Pinouts (Continued)
U2206
Pin No.
Description
Probe Points
Not Shielded Under Shield

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
