Motorola APX 7000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-57
H5 GROUND N/A
H6 GROUND N/A
H7 N/C –
J1 GROUND N/A
J2 GROUND N/A
J3 N/C –
J4 GROUND N/A
J5 N/C –
J6 MISO_TXD0 R2291, TP2205 Test point
J7 GROUND N/A
K1 FLTRD_GPS_1.2V_CO
RE (R2294)
R2294, C2273, C2278,
C2203
K2 N/C –
K3 N/C –
K4 FLTRD_GPS_1.8V_IO R2295, C2272, C2277,
C2281
K5 GROUND N/A
K6 MOSI_RXD0 R2292, TP2205 Test Point
K7 VDD_CORE4 C2286, C2287
L1 GROUND N/A
L2 GROUND N/A
L3 GROUND N/A
L4 FLTRD_GPS_1.2V_CO
RE
R2294, C2273, C2278,
C2203
L5 GROUND N/A
L6 GROUND N/A
L7 GROUND N/A
Note:
N/A = Non Accessible
Table 7-18. U2206 GPS Pinouts (Continued)
U2206
Pin No.
Description
Probe Points
Not Shielded Under Shield

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
