Motorola APX 7000 Detailed Service Manual

7-10 Troubleshooting Tables: List of Board and IC Signals
A2 DDR_ADDR 0 DDR Interface Schematic N/A
B2 DDR_ADDR 1 DDR Interface Schematic N/A
B3 DDR_BANK0 {DDR_CNTRL 2} DDR Interface Schematic N/A
B4 BBR_CAS {DDR_CNTRL 5} DDR Interface Schematic N/A
B6 DDR_ADDR 2 DDR Interface Schematic N/A
B8 DDR_ADDR 10 DDR Interface Schematic N/A
B9 DDR_ADDR 5 DDR Interface Schematic N/A
B12 DDR_ADDR 9 DDR Interface Schematic N/A
C3 DDR_BANK1 {DDR_CNTRL 3} DDR Interface Schematic N/A
C4 DDR_DATA 6 DDR Interface Schematic N/A
C5 DDR_DATA 2 DDR Interface Schematic N/A
C6 DDR_DATA 1 DDR Interface Schematic N/A
C7 DDR_DATA 5 DDR Interface Schematic N/A
C8 DDR_LDM {DDR_CNTRL 8} DDR Interface Schematic N/A
C9 DDR_CLK_1 DDR Interface Schematic TP6307
C10 DDR_DATA 8 DDR Interface Schematic TP6306
C11 DDR_DATA 12 DDR Interface Schematic N/A
C12 DDR_DATA 15 DDR Interface Schematic N/A
C13 DDR_DATA 11 DDR Interface Schematic N/A
C14 DDR_DQSH {DDR_CNTRL 9} DDR Interface Schematic N/A
D4 DDR_DQSL {DDR_CNTRL 10} DDR Interface Schematic N/A
D5 DDR_DATA 4 DDR Interface Schematic N/A
D6 DDR_DATA 0 DDR Interface Schematic TP6305
D7 DDR_DATA 3 DDR Interface Schematic N/A
D8 DDR_DATA 7 DDR Interface Schematic N/A
D9 DDR_CLKX_1 DDR Interface Schematic TP6308
D10 DDR_UDM {DDR_CNTRL 7} DDR Interface Schematic N/A
D11 DDR_DATA 10 DDR Interface Schematic N/A
D12 DDR_DATA 14 DDR Interface Schematic N/A
D13 DDR_DATA 13 DDR Interface Schematic N/A
Table 7-11. U6302 OMAP Pinouts (Continued)
U6302
Pin
No.
Description Comment
Probe Points
Not Shielded Under Shield

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
