Motorola APX 7000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-11
D14 DDR_DATA 9 DDR Interface Schematic N/A
G8 DDR_CS {DDR_CNTRL 6} DDR Interface Schematic N/A
G9 DDR_ADDR 8 DDR Interface Schematic N/A
G10 DDR_ADDR 4 DDR Interface Schematic N/A
G11 DDR_ADDR 7 DDR Interface Schematic N/A
G12 DDR_ADDR 6 DDR Interface Schematic N/A
H7 DDR_RAS {DDR_CNTRL 4} DDR Interface Schematic N/A
H8 DDR_WE {DDR_CNTRL 1} DDR Interface Schematic N/A
H9 DDR_ADDR 12 DDR Interface Schematic N/A
H10 DDR_ADDR 11 DDR Interface Schematic N/A
H11 DDR_ADDR 13 DDR Interface Schematic N/A
H12 DDR_CLKE {DDR_CNTRL 0} DDR Interface Schematic R6301
C1 FLASH_ADDR 3 Flash Interface
Schematic
N/A
D2 FLASH_ADDR 5 Flash Interface
Schematic
N/A
D3 FLASH_ADDR 2 Flash Interface
Schematic
N/A
E1 FLASH_ADDR 25 Flash Interface
Schematic
N/A
E3 FLASH_ADDR 7 Flash Interface
Schematic
N/A
E4 FLASH_ADDR 4 Flash Interface
Schematic
N/A
F2 FLASH_ADDR 20 Flash Interface
Schematic
N/A
F3 FLASH_ADDR 9 Flash Interface
Schematic
N/A
F4 FLASH_ADDR 6 Flash Interface
Schematic
N/A
G2 FLASH_ADDR 12 Flash Interface
Schematic
N/A
G3 FLASH_ADDR 11 Flash Interface
Schematic
N/A
Table 7-11. U6302 OMAP Pinouts (Continued)
U6302
Pin
No.
Description Comment
Probe Points
Not Shielded Under Shield

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
