Motorola APX 7000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-39
E4 MECH_SW MAKO Power Schematic Test Point
F_MECH_SW,
J2101_Pin 9
E12 VBUS1_SUPPLY MAKO Power Schematic R6512, R6521
E13 SW5_CUMCOMP MAKO Power Schematic R6519
E14 SW5_VSENSE MAKO Power Schematic R6518, C6552, R6533,
L6503
F3 VRTC MAKO Power Schematic R6508, C6542 R5017, C5005
F4 EMERG_PB MAKO Power Schematic R6509
F5 N/C MAKO Power Schematic –
F11 VBUS2_ISENSE MAKO Power Schematic R6531, R6532, C6557
F12 SW5_VOUT MAKO Power Schematic R6511, R6517
F13 SW5_VDDHV MAKO Power Schematic R6518, C6552, R6533,
L6503
F14 SW1_PHASE MAKO Power Schematic R6514
G4 MAKO_HV_BG MAKO Power Schematic C6540
G5 GROUND MAKO Power Schematic N/A
G11 SW5_PHASE MAKO Power Schematic R6519
G12 SW_FILT_B+ MAKO Power Schematic J3001_Pins_27,
29, 31
R6516, C6546
G13 SW1_VDD_1 MAKO Power Schematic R6520, C6545
G14 SW1_SUMCOMP_DL MAKO Power Schematic R6514
H5 GROUND MAKO Power Schematic N/A
H10 VBUS1 MAKO Power Schematic J3001_Pin 32 C6551
H11 SW_FILT_B+ MAKO Power Schematic J3001_Pins_27,
29, 31
R6516, C6546
H12 SW1_VOUT MAKO Power Schematic J4001_Pin 2,
J1001_Pin 37
R6515, C6548, L6502,
C6558, C6539, C6560,
C6561, R6542, R6543,
C6564, R6546, C6568
H13 N/C MAKO Power Schematic –
H14 GROUND MAKO Power Schematic N/A
J4 GROUND MAKO Power Schematic N/A
Table 7-15. U6501 MAKO Pinouts (Continued)
U6501
Pin No.
Description Comment
Probe Points
Not Shielded Under Shield

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
