Motorola APX 7000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-37
N8 TGO R2133, R2132, C2106,
C2108, J2101_Pin 11
N9 GROUND N/A
N10 CPLD_TMS C2101, R2115
N11 FREQ_SEL_3 R2130, C2111, J2101_Pin 12
N12 GROUND N/A
N13 CAM_FLASH_GPIO N/A
N14 CAM_PWRDN N/A
P1 VCC_INT R6107, C6105, C6106, C6107
P2 SSI_OPT_CLK J3001_Pin 57 R3006
P3 SSI_OPT_FSYNC J3001_Pin 55 R3005
P4 GROUND N/A
P5 SSI_MAKO_CLK N/A
P6 SSI_MAKO_FSYNC N/A
P7 VCC_IO1 R6101, C6108, C6109, C6110,
C6111
P8 OPT_BD_GPIO_2 J3001_Pin 45
P9 KEYLD_MISSING R6104
P10 SPI_ARM_CLK_INV R2325, J2301_Pin 31
P11 MON R6101
P12 TOP_DIS_D_C J2101_Pin 21
P13 VCC_IO1 R6101, C6108, C6109, C6110,
C6111
P14 TP6101 TP6101 TEST POINT
Note:
N/A = Non Accessible
Table 7-14. U6101 CPLD Pinouts (Continued)
U6101
Pin No.
Description
Probe Points
Not Shielded Under Shield

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
