Motorola APX 7000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-13
N3 FLASH_CNTRL 6 Flash Interface
Schematic
R6310
N4 FLASH_DATA 0 Flash Interface
Schematic
N/A
N7 FLASH_DATA 2 Flash Interface
Schematic
N/A
N8 FLASH CONTROL 1 Flash Interface
Schematic
R6311
P2 FLASH_DATA 3 Flash Interface
Schematic
N/A
P4 FLASH_DATA 4 Flash Interface
Schematic
N/A
P7 FLASH_DATA 5 Flash Interface
Schematic
N/A
P8 FLASH_DATA 11 Flash Interface
Schematic
N/A
R2 FLASH_DATA 6 Flash Interface
Schematic
N/A
R3 FLASH_DATA 7 Flash Interface
Schematic
N/A
R4 FLASH_DATA 8 Flash Interface
Schematic
N/A
T2 FLASH_DATA 9 Flash Interface
Schematic
N/A
T3 FLASH_DATA 10 Flash Interface
Schematic
N/A
T4 FLASH_DATA 14 Flash Interface
Schematic
N/A
U1 FLASH_DATA 12 Flash Interface
Schematic
N/A
U3 FLASH_DATA 13 Flash Interface
Schematic
N/A
U4 FLASH_CNTRL 2 Flash Interface
Schematic
R6312
V2 FLASH_CNTRL 7 Flash Interface
Schematic
R6309
V3 FLASH_DATA 15 Flash Interface
Schematic
N/A
Table 7-11. U6302 OMAP Pinouts (Continued)
U6302
Pin
No.
Description Comment
Probe Points
Not Shielded Under Shield

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
