Troubleshooting Tables: List of Board and IC Signals 7-31
E7 DDR_DATA 7 N/A
E8 DDR_DQSL TP6303
E9 VCC_DDR R6308, C6301, C6302, C6303,
C6304, C6305, C6306
F1 GROUND N/A
F2 DDR_UDM N/A
F3 N/C –
F7 DDR_ADDR 13 N/A
F8 DDR_LDM N/A
F9 VCC_DDR R6308, C6301, C6302, C6303,
C6304, C6305, C6306
G1 DDR_CLKE R6301
G2 DDR_CLK_1 TP6307
G3 DDR_CLKX_1 TP6308
G7 DDR_WE N/A
G8 DDR_CAS N/A
G9 DDR_RAS N/A
H1 DDR_ADDR 9 N/A
H2 DDR_ADDR 11 N/A
H3 DDR_ADDR 12 N/A
H7 DDR_CS N/A
H8 DDR_BANK 0 N/A
H9 DDR_BANK 1 N/A
J1 DDR_ADDR 6 N/A
J2 DDR_ADDR 7 N/A
J3 DDR_ADDR 8 N/A
J7 DDR_ADDR 10 N/A
J8 DDR_ADDR 0 N/A
J9 DDR_ADDR 1 N/A
K1 GROUND N/A
K2 DDR_ADDR 4 N/A
Table 7-13. U6301 DDR Pinouts (Continued)
U6301
Pin No.
Description
Probe Points
Not
Shielded
Under Shield
