Troubleshooting Tables: List of Board and IC Signals 7-45
P11 MAKO_OPTB_SEL0_GCAI MAKO Serial Interface J4001_Pin 50
P12 MAKO_OPTB_SEL2_GCAI MAKO Serial Interface N/A
P13 N/C MAKO Serial Interface –
Note:
N/A = Non Accessible
Table 7-15. U6501 MAKO Pinouts (Continued)
U6501
Pin No.
Description Comment
Probe Points
Not Shielded Under Shield
