Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1/VHF 8-155
U1125 5175206H01 IC,DAC,W/ 5 PPM/C INT REF
U1126 5109817F77 IC,COMPTR,LMV7275,SC70-5
U1127 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1128 5188085K11 IC,NAND,SINGLE 2 INPUT,
SN74LVC1G00YZPR,SM,GATE,
POS,5 DSBGA,PB-
U1129 5175143H01 IC,WIDE SPLY RANGE OP AMP
U1130 5175143H01 IC,WIDE SPLY RANGE OP AMP
U1131 5109817F77 IC,COMPTR,LMV7275,SC70-5
U1132 5114007M28 IC,F-F/D,1PER PKG,17SZ74,
N-I,SM,SOIC8,PB-FREE
U1133 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1133 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1136 `5109522E94 GATE,AND,1PER PKG,SM,2
INPUT IN NANO PKG
U1137 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1138 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1138 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1139 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1139 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1140 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1140 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1141 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
Ref. Des. Part Number Description
U1142 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1143 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1144 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1144 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1145 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1145 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1146 `5109522E93 GATE,OR,SN74LVC1G32YZPR,
1PER PKG,SM,2 INPUT IN NANO
PKG
U1147 `5109522E94 GATE,AND,1PER PKG,SM, 2
INPUT IN NANO PKG
U1148 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1304 5105739X13 IC,AMP,SIGE,QFN,QFN,18DB,
1.57GHZMIN,1.57GHZMAX,
.9DB,SIGE GPS LO
U1601 5175143H01 IC,WIDE SPLY RANGE OP AMP
U1602 5115678H01 IC,RF AMPLIFIER,BGA,
TSSOP16EP,30MHZMIN,941MHZ
MAX,VHF/UHF/800
U2032 `4885316E32 XSTR,BIP RF SML SGNL,SLCN,
BFR380F,SM,SMT,6V,380W,80A,
14MHZ,TR
VR101 4813977M29 DIODE,VREF,MBZ5250,SM, SOT-
23,20V,.225W,ZEN
VR200 4813977M29 DIODE,VREF,MBZ5250,SM, SOT-
23,20V,.225W,ZEN
VR601 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79,SOD-523/SC-79
VR602 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79,SOD-523/SC-79
VR2005 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
Ref. Des. Part Number Description
VR2006 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR2007 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR2008 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR2010 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR2020 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
Y701 4871886H01 OSC,TCXO,16.8MHZ,SM,
16.8 MHZ VCTXO .8PPM
Y704 5164852H68 OSC,VOLTAGE CONTROLLED,
411MHZ MAX,270MHZ MIN,SM,
M9LX7WX2.5H,I
Y705 5164852H66 OSC,VOLTAGE CONTROLLED,
520MHZ MAX,380MHZ MIN,SM,
M9LX7WX2.5H,I
Y706 NOT PLACED –
Y707 5164852H67 OSC,VOLTAGE CONTROLLED,
824MHZ MAX,245MHZ MIN,SM,
M9LX7WX2.5H,I
Ref. Des. Part Number Description
