8-328 Schematics, Boards Overlays, and Parts Lists: VOCON Boards
R6114 0613952Q49 CER CHIP RES 100 OHM 5 0402
R6115 0613952Q49 CER CHIP RES 100 OHM 5 0402
R6116 0613952Q73 CER CHIP RES 1000 OHM 5 0402
R6117 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6118 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6201 NOT PLACED –
R6202 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6203 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6204 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6205 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6206 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6207 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6208 0613952Q89 CER CHIP RES 4700 OHM 5 0402
R6209 0613952Q89 CER CHIP RES 4700 OHM 5 0402
R6210 0613952Q89 CER CHIP RES 4700 OHM 5 0402
R6211 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6212 NOT PLACED –
R6213 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6214 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6215 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6216 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6217 0613952Q73 CER CHIP RES 1000 OHM 5 0402
R6218 0613952Q80 CER CHIP RES 2000 OHM 5 0402
R6301 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6302 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6303 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6304 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R6305 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R6308 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
Ref. Des. Part Number Description
R6309 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6310 0613952Q37 CER CHIP RES 33.0 OHM 5 0402
R6311 0613952Q37 CER CHIP RES 33.0 OHM 5 0402
R6312 0613952Q37 CER CHIP RES 33.0 OHM 5 0402
R6313 0613952Q37 CER CHIP RES 33.0 OHM 5 0402
R6314 0613952Q37 CER CHIP RES 33.0 OHM 5 0402
R6315 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6316 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6317 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6318 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6401 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6402 0613952R32 CER CHIP RES 200K OHM 5
0402
R6403 0613952Q81 CER CHIP RES 2200 OHM 5 0402
R6404 0613952Q81 CER CHIP RES 2200 OHM 5 0402
R6405 NOT PLACED –
R6406 NOT PLACED –
R6407 0613952Q81 CER CHIP RES 2200 OHM 5 0402
R6408 NOT PLACED –
R6409 NOT PLACED –
R6410 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6411 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6412 NOT PLACED –
R6413 NOT PLACED –
R6414 0613952Q61 CER CHIP RES 330 OHM 5 0402
R6415 0613952Q61 CER CHIP RES 330 OHM 5 0402
R6416 0613952Q61 CER CHIP RES 330 OHM 5 0402
R6417 0613952Q61 CER CHIP RES 330 OHM 5 0402
R6418 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6419 0613952Q37 CER CHIP RES 33.0 OHM 5 0402
R6420 0613952R17 CER CHIP RES 47K OHM 5%
0402
R6421 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6422 0613952Q51 CER CHIP RES 120 OHM 5 0402
R6423 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6424 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
Ref. Des. Part Number Description
R6425 0613952Q80 CER CHIP RES 2000 OHM 5 0402
R6426 0613952Q49 CER CHIP RES 100 OHM 5 0402
R6427 0613952R11 CER CHIP RES 27K OHM 5%
0402
R6428 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6429 0613952R17 CER CHIP RES 47K OHM 5%
0402
R6430 0613952R09 CER CHIP RES 22K OHM 5%
0402
R6431 0613952Q81 CER CHIP RES 2200 OHM 5 0402
R6432 NOT PLACED –
R6433 NOT PLACED –
R6434 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6435 NOT PLACED –
R6436 NOT PLACED –
R6501 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R6502 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R6503 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R6504 0613952R09 CER CHIP RES 22K OHM 5%
0402
R6505 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R6506 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6507 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6508 0613952Q80 CER CHIP RES 2000 OHM 5 0402
R6509 NOT PLACED –
R6510 0613952R17 CER CHIP RES 47K OHM 5%
0402
R6511 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6512 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6513 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6514 0613952Q89 CER CHIP RES 4700 OHM 5 0402
R6515 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6516 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6517 0613952Q63 CER CHIP RES 390 OHM 5 0402
R6518 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6519 0613952Q89 CER CHIP RES 4700 OHM 5 0402
R6520 0613952Q73 CER CHIP RES 1000 OHM 5 0402
Ref. Des. Part Number Description
R6521 0615049H01 KAMAYA 0.2 OHM CHIP
RESISTOR
R6522 NOT PLACED –
R6523 0613952R09 CER CHIP RES 22K OHM 5%
0402
R6524 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6525 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6526 NOT PLACED –
R6527 0613952N87 CER CHIP RES 78.7K OHM 1
0402
R6528 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6529 0615049H01 KAMAYA 0.2 OHM CHIP
RESISTOR
R6530 0613952L30 CER CHIP RES 200 OHM 1 0402
R6531 0613952R01 CER CHIP RES 10K OHM 5%
0402
R6532 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6533 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6534 NOT PLACED –
R6535 0613952N01 CER CHIP RES 10.0K OHM 1
0402
R6536 0613952Z72 RES,MF,91KOHM,1%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R6537 0613952P09 CER CHIP RES 121K OHM 1
0402
R6538 0613952Q95 CER CHIP RES 8200 OHM 5 0402
R6539 0613952P66 CER CHIP RES 475K OHM 1
0402
R6540 0613952P66 CER CHIP RES 475K OHM 1
0402
R6541 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6542 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6543 NOT PLACED –
R6544 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R6545 0613952R25 CER CHIP RES 100K OHM 5%
0402
R6546 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6547 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R6548 NOT PLACED –
R6549 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
Ref. Des. Part Number Description
