4 - 14 MC31XX Series Mobile Computer Integrator Guide
Figure 4-10
Select Source File Window
2. Select the hex files and the click Open.
Figure 4-11
Select Hex File(s)
3. Click the LOAD button. The hex file(s) is downloaded to the device.
Figure 4-12
Download Complete Screen
4. On completion, press ENT to return to the Bootloader main screen to select the next file to download.
5. To exit Bootloader, select Exit from the Bootloader main screen and press ENT.
Splash screen
#### (20) 100%
Download complete
in - 0.042 seconds
(1854142 bytes/second)
Hit Enter to Acknowledge
Bootloader 1.09.3010
