ioLogik E2210 User’s Manual Modbus/TCP Address Mappings
B-4
Reference Address Data Type Description
00078 0x004D 1 bit
CH5 DI Counter Overflow Status
Read: 0: Normal
1: Overflow
Write: 0: clear overflow status
1: return Illegal Data Value
00079 0x004E 1 bit
CH6 DI Counter Overflow Status
Read: 0: Normal
1: Overflow
Write: 0: clear overflow status
1: return Illegal Data Value
00080 0x004F 1 bit
CH7 DI Counter Overflow Status
Read: 0: Normal
1: Overflow
Write: 0: clear overflow status
1: return Illegal Data Value
00081 0x0050 1 bit
CH8 DI Counter Overflow Status
Read: 0: Normal
1: Overflow
Write: 0: clear overflow status
1: return Illegal Data Value
00082 0x0051 1 bit
CH9 DI Counter Overflow Status
Read: 0: Normal
1: Overflow
Write: 0: clear overflow status
1: return Illegal Data Value
00083 0x0052 1 bit
CH10 DI Counter Overflow Status
Read: 0: Normal
1: Overflow
Write: 0: clear overflow status
1: return Illegal Data Value
00084 0x0053 1 bit
CH11 DI Counter Overflow Status
Read: 0: Normal
1: Overflow
Write: 0: clear overflow status
1: return Illegal Data Value
00085 0x0054 1 bit CH0 DI Counter Trigger : 0=Low to High, 1=High to Low
00086 0x0055 1 bit CH1 DI Counter Trigger : 0=Low to High, 1=High to Low
00087 0x0056 1 bit CH2 DI Counter Trigger : 0=Low to High, 1=High to Low
00088 0x0057 1 bit CH3 DI Counter Trigger : 0=Low to High, 1=High to Low
00089 0x0058 1 bit CH4 DI Counter Trigger : 0=Low to High, 1=High to Low
00090 0x0059 1 bit CH5 DI Counter Trigger : 0=Low to High, 1=High to Low
00091 0x005A 1 bit CH6 DI Counter Trigger : 0=Low to High, 1=High to Low
00092 0x005B 1 bit CH7 DI Counter Trigger : 0=Low to High, 1=High to Low
00093 0x005C 1 bit CH8 DI Counter Trigger : 0=Low to High, 1=High to Low
00094 0x005D 1 bit CH9 DI Counter Trigger : 0=Low to High, 1=High to Low
00095 0x005E 1 bit CH10 DI Counter Trigger : 0=Low to High, 1=High to Low
