Page #55 background imageLoading...
Page #55 background image
A
A
Appendix A. Liquid Crystal Display Module (LCM)
As an Easy View device, the ioLogik E2210 supports an optional detachable Liquid Crystal Display
Module (LCM) for easier field maintenance. The LCM is hot-pluggable and can be used to configure the
network settings or display other settings. When plugged in, the LCM displays the ioLogik E2210 “home
page,” and pressing any button takes you into the settings and configuration.
LCM Controls
The up and down buttons navigate between the current options. The right and left buttons enter and exit
the submenus. The center button is used when modifying settings or restarting the server.
Button Function
Up go to the previous item
Down go to the next item
Left exit the current submenu and return to the previous menu (go up one level)
Right enter the selected submenu (go down one level)
Center enter/exit editing mode
An “e” in the upper right hand corner of the display indicates that the parameter can be modified. Press the
center button on the LCM to modify that parameters settings.
LCM Options
Display Explanation / Actions
<ioLogik E2210>
This is the default “home page” showing the IP address. Press the
down button to view the submenus.
<ioLogik E2210>
server
Enter this submenu to display information about the specific server
you are viewing:
z serial number
z name
z location
z E2210 f/w ver
z lcm f/w ver
z model name
