Appendix B. Modbus/TCP Address Mappings
E2210 Modbus Mapping
0xxxx Read/Write Coils (Support Functions 1, 5, 15)
Reference Address Data Type Description
00001 0x0000 1 bit CH0 DO Value 0: Off 1: On
00002 0x0001 1 bit CH1 DO Value 0: Off 1: On
00003 0x0002 1 bit CH2 DO Value 0: Off 1: On
00004 0x0003 1 bit CH3 DO Value 0: Off 1: On
00005 0x0004 1 bit CH4 DO Value 0: Off 1: On
00006 0x0005 1 bit CH5 DO Value 0: Off 1: On
00007 0x0006 1 bit CH6 DO Value 0: Off 1: On
00008 0x0007 1 bit CH7 DO Value 0: Off 1: On
00009 0x0008 1 bit CH0 DO Power-On Value 0: Off 1: On
00010 0x0009 1 bit CH1 DO Power-On Value 0: Off 1: On
00011 0x000A 1 bit CH2 DO Power-On Value 0: Off 1: On
00012 0x000B 1 bit CH3 DO Power-On Value 0: Off 1: On
00013 0x000C 1 bit CH4 DO Power-On Value 0: Off 1: On
00014 0x000D 1 bit CH5 DO Power-On Value 0: Off 1: On
00015 0x000E 1 bit CH6 DO Power-On Value 0: Off 1: On
00016 0x000F 1 bit CH7 DO Power-On Value 0: Off 1: On
00017 0x0010 1 bit CH0 DO Safe Value 0: Off 1: On
00018 0x0011 1 bit CH1 DO Safe Value 0: Off 1: On
00019 0x0012 1 bit CH2 DO Safe Value 0: Off 1: On
00020 0x0013 1 bit CH3 DO Safe Value 0: Off 1: On
00021 0x0014 1 bit CH4 DO Safe Value 0: Off 1: On
00022 0x0015 1 bit CH5 DO Safe Value 0: Off 1: On
00023 0x0016 1 bit CH6 DO Safe Value 0: Off 1: On
00024 0x0017 1 bit CH7 DO Safe Value 0: Off 1: On
00025 0x0018 1 bit CH0 DO Pulse Operate Status 0: Off 1: On
00026 0x0019 1 bit CH1 DO Pulse Operate Status 0: Off 1: On
00027 0x001A 1 bit CH2 DO Pulse Operate Status 0: Off 1: On
00028 0x001B 1 bit CH3 DO Pulse Operate Status 0: Off 1: On
00029 0x001C 1 bit CH4 DO Pulse Operate Status 0: Off 1: On
00030 0x001D 1 bit CH5 DO Pulse Operate Status 0: Off 1: On
