ioLogik E2210 User’s Manual Click&Go Logic
5-6
THEN Actions
Under the THEN column, you may set up to 3 actions that will be performed if the conditions under the
IF column are satisfied. The 3 actions may be any combination of DI/O setting, SNMP trap, Active
Message (by TCP/UDP), or E-mail. For SNMP trap, Active Message, and E-mail actions, use the
following memo icon to additional parameters:
Summary of IF/THEN Parameters
IF Conditions Operators Remark
DI-[0 to 11] ON/OFF Depends on DI type
Counter-[0 to 11] =,>,<,>=,<=,Change Max value 4,294,967,295
Time Trigger N/A Max value 4,294,967,295
THEN Actions Operators Remark
Counter-[0 to 11] Reset Depends on DI type
DO-[0 to 7] ON/OFF Depends on DO type
Pulse Output-[0-7] Start/Stop Depends on DO type
SNMP Trap 1to 20 Details below
Active Message N/A Details below
Email N/A Details below
