ioLogik E2210 User’s Manual Introduction
1-5
Physical Dimensions
Without LCD Module (unit: mm)
24.44
5.95
9.51
79
93.02
121.8
115
10.98
6
9.5
45.39
10.7
39.5
46.51
With LCD Module (unit: mm)
45.63
10.7
6
115
121.8
79
93.02
10.98
9.5
5.95
24.44
9.51
46.51
39.5
