Moxa Technologies ioLogik E2210 User Manual

ioLogik E2210 User’s Manual Modbus/TCP Address Mappings
B-7
Reference Address Data Type Description
40017 0x0010 word CH0 DO Pulse Low Signal Width
40018 0x0011 word CH1 DO Pulse Low Signal Width
40019 0x0012 word CH2 DO Pulse Low Signal Width
40020 0x0013 word CH3 DO Pulse Low Signal Width
40021 0x0014 word CH4 DO Pulse Low Signal Width
40022 0x0015 word CH5 DO Pulse Low Signal Width
40023 0x0016 word CH6 DO Pulse Low Signal Width
40024 0x0017 word CH7 DO Pulse Low Signal Width
40025 0x0018 word CH0 DO Pulse High Signal Width
40026 0x0019 word CH1 DO Pulse High Signal Width
40027 0x001A word CH2 DO Pulse High Signal Width
40028 0x001B word CH3 DO Pulse High Signal Width
40029 0x001C word CH4 DO Pulse High Signal Width
40030 0x001D word CH5 DO Pulse High Signal Width
40031 0x001E word CH6 DO Pulse High Signal Width
40032 0x001F word CH7 DO Pulse High Signal Width
40033 0x0020 word
CH0 DO Mode 0: DO
1: Pulse
40034 0x0021 word
CH1 DO Mode 0: DO
1: Pulse
40035 0x0022 word
CH2 DO Mode 0: DO
1: Pulse
40036 0x0023 word
CH3 DO Mode 0: DO
1: Pulse
40037 0x0024 word
CH4 DO Mode 0: DO
1: Pulse
40038 0x0025 word
CH5 DO Mode 0: DO
1: Pulse
40039 0x0026 word
CH6 DO Mode 0: DO
1: Pulse
40040 0x0027 word
CH7 DO Mode 0: DO
1: Pulse
40041 0x0028 word CH0 DI / Counter Filter
40042 0x0029 word CH1 DI / Counter Filter
40043 0x002A word CH2 DI / Counter Filter
40044 0x002B word CH3 DI / Counter Filter
40045 0x002C word CH4 DI / Counter Filter
40046 0x002D word CH5 DI / Counter Filter
40047 0x002E word CH6 DI / Counter Filter
40048 0x002F word CH7 DI / Counter Filter
40049 0x0030 word CH8 DI / Counter Filter
40050 0x0031 word CH9 DI / Counter Filter
40051 0x0032 word CH10 DI / Counter Filter
40052 0x0033 word CH11 DI / Counter Filter
