Moxa Technologies NPORT 6150 User Manual

NPort 6000 Series Administration Settings
10-9
Configuration Value Description
HTTP/HTTPS console Enable/Disable This setting is to enable/disable the web console. For security
reasons, users can only enable the HTTPS or just disable all
settings.
Telnet/SSH console Enable/Disable This setting is to enable/disable the Telnet/SSH console
Moxa Service Enable/Disable This setting is to enable/disable
Moxa command service (DSCI).
NPort Windows Driver Manager and Device Search Utility cannot
be used when Moxa Service is disabled.
Maximum Login Users
For HTTP+HTTPS
1-10 Set the maximum number of users allowed on web console
Auto Logout Setting
(min)
1-1440 minutes Set the logout time period.
Console authentication
type
Local
RADIUS
RADIUS - Local
Local - RADIUS
TACACS+
TACACS+ - Local
Local – TACACS+
Set the console authentication type by dropdown menu
Try next type on
authentication denied
Enable/Disable If a user selects more than one authentication server types,
(RADIUS – Local, Local – RADIUS, TACACS+ - Local, Local –
TACACS+) NPort 6000 will make attempts on second
authentication server if the first authentication server gets
denied.
Reset button Always Enable/
Disable after 60 sec
Users can set reset button functioning at all time by selecting
Always Enable or allow reset button function only at first 60
seconds by selecting Disable after 60 sec
LCM read-only
protection
Writable/Read-only The NPort 6000 front panel, known as the LCM (Liquid Crystal
Module), may be configured for read-only or writeable access.
Read-
only access allows settings to be viewed but not changed.
Writeable access allows users in Administration group to change
the setting.
Load Factory Defaults
This function will reset all of NPort 6000’s settings to the factory default values. All previous settings, including
the console password, will be lost. If you wish to keep the NPort 6000 IP address, netmask, and other IP
settings, make sure Keep IP settings is checked off before loading the factory defaults.

Moxa Technologies NPORT 6150 Specifications

General

Display	-
Baud rate	921.6 Kbit/s
Data bits	5, 6, 7, 8
Isolation	1.5 kV
Stop bits	1, 1.5, 2
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
RS-422 signals	GND, RxD+, RxD-, TxD+, TxD-
RS-485 signals	Data+, Data-, GND, RxD+, RxD-, TxD+, TxD-
Flow Control type	RTS/CTS, XON/XOFF
Flow control support	Yes
Serial interface type	RS-232, RS-422, RS-485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Mean time between failures (MTBF)	2097705 h
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Built-in processor	No
Input voltage	12 - 48 V
Power consumption	285 mA
Power source type	DC
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4/v6, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1/V2c/V3, HTTP, SMTP, ARP, PPPoE
Security algorithms	AES, DES, SSH, SSL/TLS
Product color	Black, Blue, Grey
Housing material	Metal
Sustainability certificates	RoHS

Weight and Dimensions

Weight	700 g
Dimensions (WxDxH)	67 x 100.4 x 29 mm
