NPort 6000 Series Configuring Serial Port Operation Modes
7-28
Destination IP address: This is the IP address of the remote dial-in/ dial-out server.
Source IP address: The Source IP address is IP address assigned to this serial port.
IP netmask: The IP netmask defines the netmask, also known as the subnet mask, for the SLIP connection
TCP/IP compression (default=No): The setting of this field depends on whether the remote user’s
application requests compression.
Inactivity time (default=0 ms): This field specifies the idle time setting for auto-disconnection. A setting of 0
ms will cause the port to remain connected even if idle.
Disconnect by (default=None): If this field is set as DCD-off, the connection will be disconnected when the
DCD signal is off. If this field is set as DSR-off, the connection will be disconnected when the DSR signal is off.
Dynamic Mode
Dynamic mode integrates PPPD, SLIPD, and Terminal dial-in services. Dynamic mode automatically detects
which remote connection mode is being used, and provides corresponding services. You can individually
enable/disable PPP/SLIP/Terminal services by selecting Yes or No next to the corresponding option. Yes will
enable that type of service; No will disable it.
Authentication type (default=None): This field allows you to configure the method used, if any, to verify a
user’s ID and authorization.
Option Description
Local Verify the ID against the NPort 6000 User Table.
RADIUS Verify the ID against the external RADIUS server.
RADIUS-Local Radius authentication is tried first, switching to Local if unsuccessful.
Local-RADIUS Authentication is performed locally first, switching to Radius if unsuccessful
TACACS+ Verify the ID against the external TACACS+ server.
TACACS+-Local TACACS+ authentication is tried first, switching to Local if unsuccessful.
Local-TACACS+ Authentication is performed locally first, switching to Radius if unsuccessful
None Authentication is not required.
Try next type on authentication denied (default=Disable): The field enables or disables the system to try
next type on first authentication denied.
Disabled Mode
When the Application is set to Disable, the relevant port will be disabled.

Moxa Technologies NPORT 6150 Specifications

General

Display	-
Baud rate	921.6 Kbit/s
Data bits	5, 6, 7, 8
Isolation	1.5 kV
Stop bits	1, 1.5, 2
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
RS-422 signals	GND, RxD+, RxD-, TxD+, TxD-
RS-485 signals	Data+, Data-, GND, RxD+, RxD-, TxD+, TxD-
Flow Control type	RTS/CTS, XON/XOFF
Flow control support	Yes
Serial interface type	RS-232, RS-422, RS-485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Mean time between failures (MTBF)	2097705 h
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Built-in processor	No
Input voltage	12 - 48 V
Power consumption	285 mA
Power source type	DC
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4/v6, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1/V2c/V3, HTTP, SMTP, ARP, PPPoE
Security algorithms	AES, DES, SSH, SSL/TLS
Product color	Black, Blue, Grey
Housing material	Metal
Sustainability certificates	RoHS

Weight and Dimensions

Weight	700 g
Dimensions (WxDxH)	67 x 100.4 x 29 mm
